NVIDIA Blackwell Architecture The Ultimate Platform for
Fifth-Gen Tensor Cores
- Max AI performance with FP4 and DLSS 4
New Streaming Multiprocessors
- Optimized for neural shaders
Fourth-Gen Ray Tracing Cores
- Built for Mega Geometry
AI-Enhanced Graphics and Performance
- NVIDIA DLSS 4 with Multi Frame Generation
Game-Winning Responsiveness
- NVIDIA Reflex 2 with Frame Warp
True-to-Life Graphics
- Full ray tracing with neural rendering
Digital Humans and AI Assistants
- NVIDIA ACE
Accelerate Your Creativity
- NVIDIA Studio creator tools and technology
Enhance Any Video with AI
- NVIDIA Broadcast and ninth-gen NVIDIA Encoder
Performance and Reliability
- NVIDIA app with Game Ready and Studio Drivers
The Ultimate Gaming Display Technologies
- NVIDIA G-SYNC
WINDFORCE COOLING SYSTEM
The WINDFORCE cooling system delivers exceptional thermal performance through a combination of cutting-edge technologies. It features server-grade thermal conductive gel, innovative Hawk fans with alternate spinning, composite copper heat pipes, a large vapor chamber, 3D active fans, and screen cooling.
ASTONISHING EXTERIOR DESIGN
Drawing inspiration from water, the back panel's ripples evoke flowing water, with mirrored, frosted, and light elements reflecting the water's shimmering surface. Metal craftsmanship refines the texture, while teal and iridescent hues accentuate the serene lake. The fan's rotation creates expanding ripples, infusing natural movement into the details.
RGB LIGHTING
With 16.7M customizable color options and numerous lighting effects, you can choose any lighting effect or synchronize with other devices in GIGABYTE CONTROL CENTER.
EXCELLENCE IN ESSENTIAL | REINFORCED STRUCTURE
The reinforced metal backplate with a bent edge, securely fastened to the I/O bracket, provides exceptional structural integrity.
- General Information
- Manufacturer
- GIGABYTE Technology, Inc
- Manufacturer Website Address
- http://www.gigabyte.us
- Brand Name
- Gigabyte
- Product Line
- AERO
- Product Type
- Graphic Card
- Technical Information
- API Supported
- DirectX 12
- OpenGL 4.6
- Number of Monitors Supported
- 4
- Features
- Triple-fan Cooler
- Maximum Digital Display Resolution
- 7680 x 4320
- AI-powered
- Yes
- Processor & Chipset
- Chipset Manufacturer
- NVIDIA
- Chipset Line
- GeForce
- Chipset Series
- RTX
- Chipset Model
- RTX 5080
- Memory
- Standard Memory
- 16 GB
- Memory Technology
- GDDR7
- Bus Width
- 256 bit
- Interfaces/Ports
- Host Interface
- PCI Express 5.0
- DisplayPort
- Yes
- Number of DisplayPort Outputs
- 3
- HDMI
- Yes
- Number of HDMI Outputs
- 1
- VGA
- Yes
- Power Description
- Power Supply Wattage
- 850 W
- Power Connector
- 1x 16-pin
- Physical Characteristics
- Form Factor
- Plug-in Card
- Cooler Type
- Active Cooler
- Height
- 2"
- Width
- 5"
- Length
- 12"
- Miscellaneous
- Platform Supported
- PC
