- General Information
- Manufacturer
- In Win Development, Inc
- Manufacturer Website Address
- http://www.in-win.com.tw
- Brand Name
- In Win
- Product Type
- Gaming Computer Case
Let the Air Flow
The D5 features a widely perforated front and top panel to enhance airflow and maximize ventilation.
The PCI-E riser cable is not included.
Dual GPU Orientation
No additional brackets required; the D5's modular, rotatable PCI-E slot bracket provides users with the option to display the GPU vertically or horizontally. The complementary magnetic GPU holder is to support heavier cards.
All About Capacity
The D5 mid-tower case accommodates E-ATX motherboards up to 12" x 10" , and the latest back-connector motherboards. It supports GPUs up to 365 mm in length.
Supports ASUS BTF, MSI Project Zero Series and GIGABYTE Project STEALTH Back-Connector motherboards.
Cooling Capacity
The D5 offers versatile cooling options to appease your system configuration.
Neptune's Galactic Glamour
The D5 comes pre-installed with one Neptune AN120 fan. These silent static pressure fans feature InWin's signature Turbine Blade design for concentrated airflow, and the ARGB lighting enriches the visual aesthetics.
Details Matter Cable Management Integration
The D5 features a removable Cable Shield Cover on the front to optimize airflow, along with cable holes, cable-tie rings, and Velcro strips for efficient cable management.
Individual PSU Chamber
The individual PSU chamber provides an ideal environment for separate thermal dissipation, significantly improving the overall climate of the case.
Headphone Hanger
The cleverly designed built-in headphone hanger makes desk organization condensed and tidy.
Quick Release Panel
Both side panels of D5 are equipped with tool-less quick-release panels to access internal components easily.
Cable Management Integration
The D5 features a removable Cable Shield Cover on the front to optimize airflow, along with cable holes, cable-tie rings, and Velcro strips for efficient cable management.
Individual PSU Chamber
The individual PSU chamber provides an ideal environment for separate thermal dissipation, significantly improving the overall climate of the case.
- Warranty
- Limited Warranty
- 2 Year
- Technical Information
- Motherboard Supported
- EATX
- ATX
- Micro ATX
- Mini ITX
- Number of Fans Supported
- 7
- Fan Supported Details
Air Cooling Fans:
- Front: 3 x 120 mm / 140 mm
- Top: 3 x 120 mm / 140 mm
- Rear: 1 x 120 mm
- (1 InWin Neptune AN120 Fan Included)
- Number of Fans Installed
- 1
- Fan Size Supported
- 4.72"
- 5.51"
- Installed Fan Size
- 4.72"
- Installed Fan Size Details
- 1 x 120mm
- Features
- Built-in GPU Holder
- Cable Management
- Headset Hanger
- Window Panel
- Yes
- Window Panel Location
- Side Panel
- Bays
- Number of Internal 3.5" Bays
- 1
- Number of Internal 2.5" Bays
- 2
- Number of Internal 2.5"/3.5" Bays
- 2
- Number of Total Expansion Bays
- 5
- I/O Expansions
- Total Number of Expansion Slots
- 7
- Interfaces/Ports
- Total Number of USB Ports
- 3
- USB Port Details
- 1 x USB 3.2 Gen 2x2 Type C
- 2 x USB 3.2 Gen 1
- Total Number of Audio In Ports
- 1
- Total Number of Audio Out Ports
- 1
- Microphone
- Yes
- Headphone/Microphone Combo Port
- Yes
- Physical Characteristics
- Color Family
- Black
- Product Color
- Black
- Product Material
- SECC
- Tempered Glass
- Acrylonitrile Butadiene Styrene (ABS)
- Cooler Type
- Fan/Liquid Cooler
- Form Factor
- Mid-tower
- Maximum CPU Cooler Height
- 6.50"
- Maximum PSU Length
- 7.09"
- Maximum GPU Length
- 14.37"
- Height
- 18.6"
- Width
- 8.7"
- Depth
- 19.4"
- Weight (Approximate)
- 18.30 lb
- Miscellaneous
- Country of Origin
- Taiwan
